EN-10028-2 Chrome Moly Steels



EN 10028-2 13CrMo4-5 steel for steel with Cr., Mo.,Cr-Mo steels For high temperature and pressure vessels

EN 10028-2 13CrMo4-5 steel plate/sheet,EN 10028-2 13CrMo4-5 steel plate/sheet, under EN 10028-2 standard, we can regard 13CrMo4-5 steel plate/sheet for steel with Cr., Mo.,Cr-Mo steels used for high temperature and pressure vessels.

13CrMo4-5 steel plate is a kind of steel which with Cr., Mo.,Cr-Mo that mainly applied for high temperature and pressure vessels.The steel grade 13CrMo4-5 is according to EN 10028-2 standard which with the yield strength of 228MPa.The followings are the chemical composition and mechanical properties of EN 10028-2 13CrMo4-5 steel plate.

Chemical Composition

Grades C Mn S P Si Cr Ni Cu Mo Nb+V+Ti
13CrMo4-5 0.05- 0.17 0.40- 0.65 0.035 max 0.035 max 0.50- 0.80 1.0- 1.5 - - 0.45- 0.60 -

Mechanical Properties

Grade Permissible yield point ratio Yield Strength MPa(min) Tensile Strength MPa Elongation % (min)
13CrMo4-5 - 228 380-550 22
